Siemens SOMATOM Emotion User Manual

The series is exported to the USB device.
Prior to removing the USB device, ensure that the series is fully
exported (indicated by a message at the bottom of the task card).
5 Click the USB icon.
6 Click the displayed popup menu Safely Eject PNP Device.
7 Remove the USB device from the USB port.

• USB storage devices are not suitable for long-term storage.
• Do not plug in or unplug USB devices during acquisition tasks or
other critical processes.
• To import data from a USB device to the database, choose
Transfer > Import from Off-line.
Networking
If your system is connected to a network, you can send data to other
workstations via the network.
1 In Patient Browser, select the data you want to transfer via
network.
8.4
Documenting and reporting 8
SOMATOM Emotion | syngo CT VC50
Print No. HC-C2-025.626.01.01.02
77

Siemens SOMATOM Emotion Specifications

General

Type	CT Scanner
Gantry aperture	70 cm
Tube voltage	80, 110, 130 kV
Maximum scan range	200 cm
Maximum Scan Field of View	50 cm
Generator Power	32 kW
Image Matrix	512 x 512
Rotation time	0.8 s, 1.0 s, 1.5 s, 2.0 s (depending on configuration)
Patient weight capacity	200 kg
Table Weight Limit	200 kg
Image Reconstruction Time	Up to 8 images/second
