Siemens SQM41 Series Technical Instructions

Technical Instructions SQM40/41…Actuators
Document No. 7817US
October 6, 2010
2
Product Numbers SQM40…Counterclockwise Table 1
Product no. Torque
(lb-in)
Time
1
(90° @
60 Hz;
sec)
Control Board Shaft Approvals Operating
voltage
1000Ω position
feedback
Modulating
3-position 2-position
Switches
Relay
C-UL-US
CE
AC120V AC230V
SQM40.144R11SC 45 12.5 x 3 3/8" square x x x
SQM40.145R11SC 45 12.5 x 3 10mm D x x x
SQM40.164R11SC 45 12.5 x 6 3/8" square x x x x
SQM40.165R11SC 45 12.5 x 6 10mm D x x x x
SQM40.174R10SC 45 12.5 x 5 1 3/8" square x x x
SQM40.241A11SC 90 25 x 3 10mm key x x
SQM40.241A21SC 90 25 x 3 10mm key x x
SQM40.241R11SC 90 25 x 3 10mm key x x x
SQM40.244A21SC 90 25 x 3 3/8" square x

x
SQM40.244R11SC 90 25 x 3 3/8" square x x x
SQM40.245R11SC 90 25 x 3 10mm D x x x
SQM40.261A11SC 90 25 x 6 10mm key x x x
SQM40.261A21SC 90 25 x 6 10mm key x x x
SQM40.261R11SC 90 25 x 6 10mm key x x x x
SQM40.264A21SC 90 25 x 6 3/8" square x x x
SQM40.264R11SC 90 25 x 6 3/8" square x x x x
SQM40.265R11SC 90 25 x 6 10mm D x x x x
SQM40.271R10SC 90 25 x 5 1 10mm key x x x
SQM40.274R10SC 90 25 x 5 1 3/8" square x x x
1. For 50 Hz, multiply running time by 1.2
