Technical Instructions SQM40/41…Actuators
Document No. 7817US
October 6, 2010
4
Product Number Identification Legend
For actuator identification only. To select product numbers for ordering, see Tables 1 & 2
SQM4
0 . 2 6 1 A 1 0 SC
Basic Type
0 counterclockwise
1 clockwise
Torque (Time)
1 45 in-lb (12 sec)
2 90 in-lb (25 sec)
PCB type/ Switches
4 3 switches, modulating version
6 6 switches, position proportional control
7 5 switches, position proportional control + relay
Shaft
1 10 mm woodruff
4 HW square type
5 10 mm D type
7 14 mm parallel key
Regional Versions
A European version, CE
R US version, C-UL-US & CE
Voltage
1 120 Vac @ 50-60 Hz
2 230 Vac @ 50-60 Hz
Potentiometer
0None
1 Single, 1000 Ohms 90°
2 Double, 2*1000 Ohms 90°
NOTE: Not all possible combinations are available
