Technical Instructions SQM40/41…Actuators
Document No. 7817US
October 6, 2010
5
Technical Data
Agency approvals C-UL-US, CE
Operating voltage 120 Vac -15% / +10%
230 Vac -15% / +10%
Operating frequency 50 to 60 Hz
Power consumption 10 VA
Type of motor Reversing synchronous motor
Duty cycle 100%
Torque See tables 1 and 2
Timings See tables 1 and 2
Rotational range of operation Maximum 90°
Direction of rotation
SQM40… Counterclockwise
SQM41… Clockwise
Shaft See tables 1 and 2
Shaft disengagement Lever actuated clutch
Number of auxiliary switches
SQM4x.x4xxx 1
SQM4x.x6xxx 4
SQM4x.x7xxx 3
Number of limit switches 2
Electrical rating of auxiliary switches 1 A, 250 Vac
Mounting position No restrictions
Ambient operating temperature -22°F to 140°F (-30°C to 60°C)
Shipping/storage temperature -22°F to 140°F (-30°C to 60°C)
NEMA ratings 1, 2, 3, 3R, 4, 5, 12 and 13
Connections
Wiring Terminal strips
Conduit ½” NPT (R version)
M16 cord grips (A version)
Dimensions See pages 11-13
Weight 4.4 lbs (2 kg)
Housing Aluminum die cast
Gears and Bearings Maintenance free
Mounting Face mounting with three self-
tapping M5 screws around shaft.
Or via four M5 clearance holes at
corners of housing.
Adaptation of Honeywell Mod IV actuators Screw pattern and shaft height
adaptation with AGA57.5
General unit data
