Siemens SQM41 Series Technical Instructions

Technical Instructions SQM40/41…Actuators
Document No. 7817US
October 6, 2010
3
Product Numbers SQM41…Clockwise Table 2
Product no. Torque
(lb-in)
Time
1
(90° @
60 Hz;
sec)
Control Board Shaft Approvals Operating
voltage
1000Ω position
feedback
Modulating
3-position 2-position
Switches
Relay
C-UL-US
CE
AC120V AC230V
SQM41.144R11SC 45 12.5 x 3 3/8" square x x x
SQM41.145R11SC 45 12.5 x 3 10mm D x x x
SQM41.164R11SC 45 12.5 x 6 3/8" square x x x x
SQM41.165R11SC 45 12.5 x 6 10mm D x x x x
SQM41.174R10SC 45 12.5 x 5 1 3/8" square x x x
SQM41.241A11SC 90 25 x 3 10mm key x x
SQM41.241A21SC 90 25 x 3 10mm key x x
SQM41.241R11SC 90 25 x 3 10mm key x x x
SQM41.244A21SC 90 25 x 3 3/8" square x x
SQM41.244R11SC 90 25 x 3 3/8" square x x x
SQM41.245R11SC 90 25 x 3 10mm D x x x
SQM41.261A11SC 90 25 x 6 10mm key x x x
SQM41.261A21SC 90 25 x 6 10mm key x x x
SQM41.261R11SC 90 25 x 6 10mm key x x x x
SQM41.264A21SC 90 25 x 6 3/8" square x x x
SQM41.264R11SC 90 25 x 6 3/8" square x x x x
SQM41.265R11SC 90 25 x 6 10mm D x x x x
SQM41.271R10SC 90 25 x 5 1 10mm key x x x
SQM41.274R10SC 90 25 x 5 1 3/8" square x x x
1. For 50 Hz, multiply running time by 1.2
Accessories Table 3
Each SQM40/41…actuator comes equipped with the appropriate power supply connection plate and terminal
connection kit. Replacement or spare components available as accessories.
Power supply connection plate
AGA45.11 Replacement conduit cover with 1/2" NPT threaded holes
AGA45.12 Replacement conduit cover with M16 unthreaded holes
Terminal connector kits
AGA45.4 Terminal plug kit for modulating (analog) version
AGA45.6 Terminal plug kit for line voltage version
Mounting brackets
AGA57.5 for replacement of Honeywell Modutrol actuators
