Siemens TUTORbit POL895 - Heating Zones, DHW Produced by AGUADENS-T, DHW Return, Solar, Antilegionella Shuffle Pump and 3 Modules Dedicated to Heating

48
TUTORBIT
COSMOGAS
4.21.10 - 3 heating zones, DHW produced by AGUADENS-T, DHW return, solar, antilegionella shu󰀪e pump and 3 modules dedicated to heating Figure 4-31 - Hydraulic connection Settings: Conguration > System > Number of Modules 4 Module 1 Heating Module 2 Heating Module 3 Heating Module 4 DHW Outdoor sensor Yes DHW Yes DHW return sensor Yes DHW Mode Sensor Unit of measure °C Number of Zones 3 Antilegionella Yes
Shu󰀪e type pump Antilegionella Solar Yes Solar Atistagnation Yes Solar Antifrost Yes Modbus enable No Heat pump No Conguration > Zones > 3 way valve > 3 way valve 1> Zone type Mix Conguration > Zones > 3 way valve > 3 way valve 2> Zone type Mix Conguration > Zones > 3 way valve > 3 way valve 3> Zone type Mix
Pay attention to Relè R1 (94) to stop AGUADENS-T when the storage tank charging is nished.
