Siemens TUTORbit POL895 User Manual

87
TUTORBIT
COSMOGAS
Continued on the next page
6 - USE
Module 4 Service supplied by heat generator 4
Installer Value Value
T. Module 1 Heat generator 1 supply temperature. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
T. Module 2 Heat generator 2 supply temperature. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
T. Module 3 Heat generator 3 supply temperature. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
T. Module 4 Heat generator 4 supply temperature. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Pressure 1 Heat generator 1 water pressure read on the Modbus channel. Visible only if Conguration>System>Modbus
enable=Yes
Installer Value Value
Pressure 2 Heat generator 2 water pressure read on the Modbus channel. Visible only if Conguration>System>Modbus
enable=Yes
Installer Value Value
Pressure 3 Heat generator 3 water pressure read on the Modbus channel. Visible only if Conguration>System>Modbus
enable=Yes
Installer Value Value
Pressure 4 Heat generator 4 water pressure read on the Modbus channel. Visible only if Conguration>System>Modbus
enable=Yes
Installer Value Value
0-10V 1 0-10V signal value received by the heat generator and read on the Modbus channel. Visible only if
Conguration>System>Modbus enable=Yes
Installer Value Value
0-10V 2 0-10V signal value received by the heat generator and read on the Modbus channel. Visible only if
Conguration>System>Modbus enable=Yes
Installer Value Value
0-10V 3 0-10V signal value received by the heat generator and read on the Modbus channel. Visible only if
Conguration>System>Modbus enable=Yes
Installer Value Value
0-10V 4 0-10V signal value received by the heat generator and read on the Modbus channel. Visible only if
Conguration>System>Modbus enable=Yes
Installer Value Value
Burners mod 1 Modbus parameters read on Heat generator 1. Visible only if Conguration>System>Modbus enable=Yes
Installer
Burner 1 Error Error on Burner 1. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 1 Power Burner 1 power percentage. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 2 Error Error on Burner 2. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 2 Power Burner 2 power percentage. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 3 Error Error on Burner 3. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 3 Power Burner 3 power percentage. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 4 Error Error on Burner 4. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burner 4 Power Burner 4 power percentage. Visible only if Conguration>System>Modbus enable=Yes
Installer Value Value
Burners mod 2 Modbus parameters read on Heat generator 2. Visible only if Conguration>System>Modbus enable=Yes
Installer
Same menu as for “Burners mod 1”
Installer
Burners mod 3 Modbus parameters read on Heat generator 3. Visible only if Conguration>System>Modbus enable=Yes
Installer
Same menu as for “Burners mod 1”
Installer
Burners mod 4 Modbus parameters read on Heat generator 4. Visible only if Conguration>System>Modbus enable=Yes
Installer
Same menu as for “Burners mod 1”
Installer
Time Cmd
1 0.0% 2 0.0% 3 0.0% 4 0.0%
Percentage of 0-10V signal sent to heat generators 1, 2, 3, 4.
Installer
