Siemens VRD Series User Manual

VRD4 Series Double Valves Technical Instructions
Document Number CC1N7649us
September 08, 2016
Siemens AG Building Technologies Division Page 9
Dimensions, continued
Dimensions in Inches (mm)
(Shipment conditions: Mounted base plates on both sides)
VRD40.065UF / VRD40.080UF / VRD40.100UF / VRD40.150UF
M
V
S
G
A
F
a)
a)
7649m05us/1215
1/4" 1/4"
1/4"
a) Base plate
Table 5. VRD40.xxxUx dimensions in inches (mm)
Type A
inch
(mm)
B
inch
(mm)
C
inch
(mm)
D
inch
(mm)
E
inch
(mm)
F
inch
(mm)
G
inch
(mm)
H
inch
(mm)
I
inch
(mm)
J
inch
NPT
K (SW*)
inch
(mm)
L (d =)
inch
(mm)
M (d =)
inch
(mm)
S
inch
(mm)
T
inch
(mm)
U
inch
(mm)
V
inch
(mm)
VRD40.040U 10.24
(260)
7.76
(197)
3.11
(79)
4.53
(115)
1.97
(50)
0.55
(14)
3.46
(88)
5.35
(136)
1.18
(30)
1½" 2.76
(70)
--- --- 0.83
(21)
2.8
(71)
--- ---
VRD40.050U 10.24
(260)
7.76
(197)
3.11
(79)
4.53
(115)
1.97
(50)
0.55
(14)
3.46
(88)
5.35
(136)
1.18
(30)
2" 3.15
(80)
--- --- 0.83
(21)
2.8
(71)
--- ---
VRD40.065UF 11.42
(290)
8.54
(217)
3.25
(82.5)
4.63
(117.5)
2.09
(53.1)
1.46
(37)
4.02
(102)
6.14
(156)
0.63
(16)
--- --- 5.5
(139.7)
0.75
(19)
1.77
(45)
3.64
(92.5)
0.80
(20.4)
7.01
(178)
VRD40.080UF 12.20
(310)
9.39
(238.5)
3.64
(92.5)
5.18
(131.5)
2.09
(47)
0.79
(20)
4.21
(107)
6.30
(160)
0.63
(16)
--- --- 6.0
(152.4)
0.75
(19)
1.2
(30.5)
3.94
(100)
0.88
(22.4)
7.56
(192)
VRD40.100UF 13.78
(350)
10.52
(267.3)
4.33
(110)
5.70
(144.8)
1.93
(49)
1.95
(49.5)
5.16
(131)
7.56
(192)
0.63
(16)
--- --- 7.5
(190.5)
0.75
(19)
2.83
(72)
4.55
(115.5)
0.87
(22)
8.74
(222)
VRD40.150UF 18.90
(480)
13.29
(337.5)
5.71
(145)
7.40
(188)
2.09
(53)
2.30
(58.5)
6.61
(168)
10.31
(262)
0.63
(16)
--- --- 9.5
(241)
0.91
(23)
3.54
(90)
5.61
(142.5)
0.90
(22.9)
10.63
(270)
* SW = width across flats
