Siemens XDLC User Manual

Siemens Industry, Inc.
Building Technologies Division
A6V101040156_en--_c5
Figure 4
XDLC Wiring Diagram
ZONE 3-6
INITIATING
DEVICE
CC-5
LINE 1
LINE 1
ZONE 4-8
LINE 2
LINE 2
SHIELD (OPTIONAL)
TERMINATE IN ENCLOSURE
WITH THE XDLC. TERMINAT
E
AT ONE END ONLY.
TERMINATE TO EARTH
GROUND.
*
*
ZONE 3-5
INITIATING
DEVICE
ZONE 4-7
SHIELD (OPTIONAL)
TERMINATE IN ENCLOSURE
WITH THE XDLC. TERMINATE
AT ONE END ONLY.
TERMINATE TO EARTH
GROUND.
*
*
9 10 11 12 13 14 15 16
***OPERATES IN FULL CONFORMANCE WITH CLASS B (ULC DCLB)
1 2 3 4 5 6 7 8
ZONE 1-2
INITIATING
DEVICE
CC-5
LINE 1
LINE 1
ZONE 2-4
LINE 2
LINE 2
SHIELD (OPTIONAL)
TERMINATE IN ENCLOSURE
WITH THE XDLC. TERMINATE
AT ONE END ONLY.
TERMINATE TO EARTH
GROUND.
*
*
CLASS B WIRING***
T-TAPPING ALLOWED
ZONE 1-1
INITIATING
DEVICE
ZONE 2-3
SHIELD (OPTIONAL)
TERMINATE IN ENCLOSURE
WITH THE XDLC. TERMINATE
AT ONE END ONLY.
TERMINATE TO EARTH
GROUND.
*
*
LINE 2 (OUT)
9 10 11 12 13 14 15 16
**OPERATES IN FULL CONFORMANCE WITH CLASS A (ULC DCLA)
1 2 3 4 5 6 7 8
ZONE 1
INITIATING
DEVICE
CC-5
LINE 1 (RETURN) LINE 1 (RETURN)
LINE 1 (OUT) LINE 1 (OUT)
ZONE 2
LINE 2 (OUT) LINE 2 (OUT)
LINE 2 (RETURN)
LINE 2 (RETURN)
*
*
CLASS A or CLASS X WIRING**
NO T-TAPPING ALLOWED
ZONE 3
INITIATING
DEVICE
CC-5
LINE 1 (RETURN) LINE 1 (RETURN)
LINE 1 (OUT) LINE 1 (OUT)
ZONE 4
LINE 2 (OUT)
LINE 2 (RETURN) LINE 2 (RETURN)
*
*
NOTES:
1. NO END OF LINE DEVICE REQUIRED.
2. ALL CIRCUITS SUPERVISED AND POWER LIMITED PER NEC 760.
3. POSITIVE OR NEGATIVE GROUND FAULT DETECTED AT <50K OHMS ON TERMINALS 1-16.
LINE 1 LINE 2 LINE 1 LINE 2
LINE 1 LINE 2
LINE 1
LINE 2
