Human-machine interface and its operation
Rem IP 192.188.110.101
Sending port 2040
Tip; Modi need Manual reboot
Figure 19 CSC-1321 Ethernet TCP client-site channel parameters display interface
Move the cursor to the connection port, and press the up or down key to alter
the port number.
Move the cursor to the remote IP address, and press the up or down key to
change the IP address
Then, press SET to confirm your modification.
◆
Ethernet UDP configuration
Interface of Ethernet UDP configuration is shown as follows:
[2-3-1-1] 1/1
Receiving IP 192.188.110.101
Receiving port 2406
Sending IP 236.008.008.008
Sending port 1888
Tip; Modi need Manual reboot
Figure 20 CSC-1321 Ethernet UDP channel parameters display interface
◆
Ethernet UDP2000 Configuration
Interface of Ethernet UDP2000 configuration is shown as follows:
[2-3-1-1] 1/1
IP1 192.168.110.101
IP2 192.168.110.102
IP3 192.168.110.103
Receiving port 1 1888
Receiving port 2 1888
Sending port 1889
Figure 21 Interface of CSC-1321 Ethernet UDP2000 channel parameters
Move the cursor to the address of IP1, IP2, and IP3 respectively, and press
