Human-machine interface and its operation
“Automatic time synchronization Stop” means this function is disabled, and to
switch its state, press the up or down key after choosing “out” menu through
left or right key.
“Adjusting time 16” means the system would adjust time for all devices
installed at 16 O’clock, whenever this function is accessible. To modify the
adjusting time, first, press the left or right key to choose “16”, and press the up
or down key to do adjustment (within 0~23). As to above modifications, press
SET to enable them, QUIT to cancel or log out.
[3-2] 1/1
Sync Time Turn Off
Set Sync Time 16
Top:SET key to Confirm
QUIT Key To Cancel
Figure 24 CSC-1321 automatic time synchronization interface
3.4 Event Information
As a submenu of event information, real-time information is a kind of
information saved during the loop when the device is on power, while to be
lost when the power is off. It can be divided into protection event, alarm event,
telesignalisation event and communication event, function of which all
depends on their enable/disable function respectively.
[4] 1/1
Real-time Info
Figure 25 CSC-1321 event information interface
If functions of the four events are all accessible, interface of menu appears
after entering real-time information as follows:
[4-1] 1/1
To Next Page
