Human-machine interface and its operation
Fault event
Alarm event
Dig event
Comm event
Figure 26 CSC-1321 event information interface
If only protection event and communication event are accessible and
the other two items are disabled, interface of the menu is shown as
follows:
[4-1] 1/1
Fault event
Comm event
Figure 27 CSC-1321 event information interface
3.4.1 Communication event
Move the cursor to the “Communication event” under the menu of real-time
information, and press SET to enter the following interface.
Real T ime Info:Comm Ev ent
3/34
2005-11-23 12:27:10
module 1 Active
2005-11-23 20:34:20
module 3 Active
2005-11-23 20:34:26
module 2 Active
Figure 28 CSC-1321event information interface
Event information arranged by the order of time can be seen in this interface,
including time, device, and event type. Press the up or down key to turn the
page while reading and long pressing can accelerate the page turning speed.
Press QUIT to log out.
