Human-machine interface and its operation
3.5 Local settings
In local settings, you can modify the address of outer net IP1 and IP2 of the
main CPU modules, clean up all the event information recorded, set all the
indicator lights enable, and set the interface enable of all information.
3.6 LCD adjustment
LCD adjustment is to adjust the effect of LCD, including display contrast and
the automatic out time of backlight.
[6] 1/1
Contrast
Backlight time
Figure 30 CSC-1321 LCD adjustment submenu interface
3.6.1 Display contrast
Press SET while the cursor is at the display contrast menu of LCD adjustment
to enter the interface of contrast settings, shown as follows:
[6-1]
LCD test
UP or DOWN to Set Contrast
Figure 31 CSC-1321 LCD contrast adjustment interface
In the interface, press the up or down key to adjust its contrast, and the
adjusted effect can be seen simultaneously.
3.6.2 Backlight time
Press SET while the cursor is at the backlight time menu of LCD adjustment
to enter the following interface of backlight time settings:.
[6-2]
