Human-machine interface and its operation
Setting Backlighting Time
05 Min
Figure 32 Interface of LCD backlight time adjustment of CSC-1321
When in this interface, press the up or down key to adjust the backlight time
within 00~99, which indicates the time limit of backlight. For example, if
setting its value into 15, then the backlight would be out 15 minutes of
no-operation; if setting it into 0, the backlight would be long bright and won’t
be quenched.
After setting, press SET to confirm the adjustment, or QUIT to cancel.
3.7 Language
Language menu is to set the language (simplified Chinese，English) of LCD
display. Press the left or right key of the four buttons to enter the following
language setting interface:
[7] 语言(Language) 1/1
简体中文
Englsih
Figure 33 CSC-1321 LCD display language settings interface
