94 SDG2000X User Manual
 Last: includes all system parameters and states, except channel output
state.
 Default: denotes the factory defaults except certain parameters (such as
Language).
4. Set to Default
Press Utility → System → Set To Default, to set the system to the default
setting. The default settings of the system are as followed:
Table 2-32 Factory Default Setting
Output
Default
Function
Sine Wave
Frequency
1kHz
Amplitude/Offset
4Vpp/0Vdc
Phase
0°
Load
High Z
Modulation
Default
Carrier
1kHz Sine Wave
Modulating
100Hz Sine Wave
AM Depth
100％
FM Deviation
100Hz
ASK Key Frequency
100Hz
FSK Key Frequency
100Hz
FSK Hop Frequency
1MHz
PSK Key Frequency
100Hz
PM Phase Deviation
100°
PWM Width Dev
190μs
Sweep
Default
Start/Stop Frequency
500Hz/1.5kHz
Sweep Time
1s
Trig Out
Off
Mode
Linear
