Chapter 2 Quick Start
One of the first things you will want to do with your generator is to become
acquainted with the front panel. We have written the exercises in this chapter
to prepare the instrument for use and help you get familiar with some of its
front-panel operations. This chapter is divided into the following sections:
⚫ To Prepare the Generator for Use
⚫ To Adjust the Carrying Handle
⚫ To Set the Output Frequency
⚫ To Set the Output Amplitude
⚫ To Set a DC Offset Voltage
⚫ To Set the Duty Cycle of a Square Waveform
⚫ To Set the Symmetry of a Ramp Waveform
⚫ To Configure a Pulse Waveform
⚫ To Configure a Noise Waveform
⚫ To Set the DC Voltage
⚫ To Output a Built-In Arbitrary Waveform
⚫ To Use the Built-In Help System
