The SDG2000X Series Generator at a Glance
SIGLENT’s SDG2000X is a series of dual-channel function/arbitrary waveform
generators with specifications of up to 120 MHz maximum bandwidth,
1.2GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb
& EasyPulse techniques help to solve the weaknesses inherent in traditional
DDS generators when generating arbitrary, square and pulse waveforms.
Using these techniques the SDG2000X provides users with a variety of high
fidelity, low jitter signals in order to meet the growing requirements for a
multitude of complex applications.
Characteristics
The powerful feature set for the SDG2000X generator family includes:
Dual-channel, 120 MHz maximum bandwidth, 20 Vpp maximum output amplitude,
high fidelity output with 80dB dynamic range
High-performance sampling system with 1.2 GSa/s sampling rate and 16-bit vertical
resolution. No detail in your waveforms will be lost
Innovative TrueArb technology, based on a point-by-point architecture, supports any
8 pts ~ 8 Mpts Arb waveform with a sampling rate in range of 1 μSa/s ~ 75 MSa/s
Innovative Easy Pulse technology, capable of generating lower jitter Square or Pulse
waveforms, brings a wide range and extremely high precision in pulse width and
rise/fall times adjustment
Plenty of analog and digital modulation types: AM、DSB-AM、FM、PM、FSK、ASK、
PSK and PWM
Sweep and Burst function
High precision Frequency Counter
Standard interfaces: USB Host, USB Device（USBTMC）, LAN（VXI-11）
Optional interface: GPIB
4.3” touch screen display for easier operation
Note: All the specifications described in this manual refer to the SDG2122X.
