To Output a Built-In Arbitrary Waveform
There are approximately 200 built-in arbitrary waveforms stored in non-volatile
memory. The following steps show how to output the built-in “exponential fall”
waveform from the front panel.
1. Set the arbitrary waveform function
Press Waveforms → Page 1/2 → Arb Type → Built-In to enter the arbitrary
waveform setting interface.
2. Set the Math waveform
Press the Math softkey to display the mathematic waveform as below.
