Check the Channel Board
If it is desired to remove the channel board from the metal shelf inside the
generator, please place it on a clean, insulated mat. Here are the procedures
for testing the main board:
1. Several types of connectors are used on the channel board. Check to
make certain that all of these are connected properly.
2. After checking these connectors, then connect the generator to AC power
and power it on. Check if the voltage values at all test points are within the
specified range using a digital multimeter. The voltage parameters to be
tested are listed in table 5-4:
Voltage Checking
Test the voltage points on the channel board in the table below. To locate the
test points, please refer to the drawing of the channel board. If not each tested
voltage value is within the corresponding spec range referring to table 5-4, it
proves to be faulted, please return it to the factory to have it repaired or contact
SIGLENT.
Table 5-4 Test Voltages of the Channel Board
Test point
Voltage value
Error limit
+15 V
+15 V
±5%
-15 V
-15 V
±5%
-5 V
-5 V
±5%
+5 V
+5 V
±5%
VCC1.8 V
+1.8 V
±5%
VCC3.3 V
+3.3 V
±5%
VCC2.5 V_A
+2.5 V
±5%
VCC2.5 V_B
+2.5 V
±5%
VCC1.5 V
+1.5 V
±5%
VCC1.1 V
+1.1 V
±5%
PLL_3.3 V
+3.3 V
±5%
