Instructions, use and maintenance manual Pag. 29/48
SRIZZA 40
14.5.1. Replacing the felt and fixing the new cloth
When replacing a worn or torn belt:
Release the clamp by loosening the screw and removing the ring.
Remove and discard the old cloth.
Clean the ring using a delicate cleanser and dry thoroughly.
Insert the new cloth.
Put the clamp back and tighten, cut the excess cloth.
Clean and flour the new cloth before using the machine.
1) DISC DIAMETER
2) CLOTH STRUCTURE
3) CLAMP
4) NEW CLOTH
INTERVAL METHOD
s F, M
FOR ANY MAINTENANCE AND CLEANING OPERATIONS, THE MACHINE MUST BE
OFF AND DISCONNECTED FROM THE ELECTRIC LINE.
Before performing any of the following operations, wear PPE such as: shoes with
reinforced tip and non-slip sole, gloves.
The following operations are ONLY necessary to tension the chain, if case of
replacement, contact the seller.
