Usermanual Motors 902x_903x Page 9
5.7 Mains Connection and Wiring of
SG 9030 - 9033 (24V DC)
Wiring: The motors SG 9030 - 9033 are always connected with perma-
nent power.
5.8 DIP - Switch Settings of SG 9020 - 9023
(90 - 250V AC/260V AC CB)
and SG 9030 - 9033 (24V DC)
The DIP Switches are used to set the motor depending on the wiring
and the required operation mode. Following table shows the
possibilities.
+
-
ON
1 2 3
ON
1 2 3
DIP Switch Position
"off-off-off"
DIP Switch Position
"on-on-on"
