Silver Peak Hardware Reference Guide
Copyright © September 2018 by Silver Peak Systems, Inc. All rights reserved
149
mgmt0 & mgmt1
Not connected 10 Mbps 100 Mbps 1000 Mbps
Speed = solid
Link/Activity:
l solid = link
l blinking = traffic
Network interfaces
Link/Activity:
l solid green = link good
l blinking green = traffic
system bypass mode
l Ports 0 + 2 – solid green
l Ports 1 + 3 – OFF
slave ports
not in system bypass
l Ports 0 + 2 – OFF
l Ports 1 + 3 – solid green
