Silver Peak Hardware Reference Guide
Copyright © September 2018 by Silver Peak Systems, Inc. All rights reserved
176
mgmt0 & mgmt1
Not connected 10 Mbps 100 Mbps 1000 Mbps
Speed = solid
Link/Activity:
l solid = link
l blinking = traffic
tlan0 / twan0 — 10 Gbps fiber interfaces
All LEDs are green
Link = solid
Activity = blinking
You have the option to separately order LR (Long Reach) 10 Gbps fiber transceivers to replace the default SR
(Short Reach) transceivers in this appliance.
These transceivers are hot-swappable.
You can distinguish the SR transceiver from the LR transceiver by the number on the label and the color of
the handle. For details, see Installing a Fiber Interface Transceiver.
