1. Overview
1 Button and LED for the vacuum function (for containers and bags with the valve
above the connection|6)
2 Button and LED for the seal film function (no vacuum)
3 Button and LED for the vacuum + seal film function
4 Power cable with mains plug
5 Opening for the power cable on the underside of the device
6 Connection for vacuum tubes|17
7 Button for opening the lid (left and right)
8 Sealing strip
9 Upper sealing ring
10 Lid
11 Rear reference ridge
12 Suction nozzle (for the vacuum + seal film function)
13 Side reference ridge
14 Lower sealing ring
15 Welding wire
16 Collector for liquids (removable)
Figure A:
17 Vacuum tubes (60 cm)
18 Adapter A (e.g. for Ernesto containers* and FoodSaver lunchboxes**)
19 Adapter B (e.g. for FoodSaver freshness containers**)
20 Adapter C (e.g. for CASO containers** and FoodSaver storage boxes**)
* not included in items supplied
** Containers from other manufacturers - not included in items supplied.
CASO is a registered brand of Caso Holding GmbH
FoodSaver is a registered brand of Sunbeam Products, Inc.
Figure B:
21 Cable spool at the underside of the device
