4 Programming of the functions ( C )
If you wish to change the works setting for the functions ( C ) ,continue to
press Parameter ( P ) until the number 23 appears. Change it to 22 and confirm
it by pressing the
key. The functions ( C ) are now accessible.
Note:
On the standard control unit (FX2004-FX5100), standard functions and parameters
are stored before dispatch.
The values in brackets correspond to the presetting ex works.
For easier comprehension, the works settings are used in the elucidations given in
these operating instructions. They are printed in bold type.
5 Selection of the functions ( C ) by pressing the key
C0=0.00 Standard control unit (FX2004 – FX5100)
C0=0.10 FX 2002 control unit
5.1 Selection for standard control unit (C0=0.00)
5.1.1 C1 flush function (0.10)
(also refer to C4 minimum flap opening time, C5 flushing delay and C6 flushing time)
C1 = 0.00 No flushing function.
C1 = 0.10
Flushing on opening the flap.
Flushing is carried out for 1 sec. (C6 flushing time) as soon as the
flap opens.
C1 = 0.20
Flushing on closing the flap.
Flushing is carried for 1 sec. (C6 flushing time) as soon as the
flap closes.
C1 = 0.30
Flushing on opening and closing the flap.
Flushing is carried out for 1 sec. (C6 flushing time) as soon as the
flap opens and for1 sec. (C6 flushing time) when the flap closes.
If there is a flap position failure, a flushing process is triggered for 1 sec.
(C6 flushing time) and a fault message is output.
