6 Selection of parameters for FX 2002 control unit
(C0=0.10)
6.1 P1 Conveying time
P1 = X.XX
X.XX sec. conveying time (without timing valve).
With connected timing valve. P1 active = valve open.
6.2 P2 Paus time
P2 = X.XX
X.XX sec. pause time (without timing valve).
With connected timing valve. P2 active = valve closed.
6.3 P3 – P6 Reserve
P3 – P6 = X.XX Reserve, no parameter.
7 Terminals
230 VAC in/outputs (6,3 mm flat connectors)
X1 L1
X2 PE
X3 PE
X4 Motor N 1,0kVA
X5 Motor L 1,0kVA
X6 N1
24V DC outputs (2,8mm flat connectors) 24V DC inputs (2,8mm flat connectors)
ST 1 and ST 2 Back wash valve 12W ST11 light barrier input
ST 3 and ST 4 Mixing valve 12W ST12 0V
ST 5 and ST 6 Clean out valve 12W ST13 Reed contact input
ST 7 and ST 8 Fault lamp,internal 2W ST14 0V
ST 9 and ST10 Fault lamp,external 12W ST15 +24V
ST16 0V
ST17 +24V
If box XD1 is used, following
ST18 0V
wiring is valid
cable No. to control unit-FX
1 ST15
2 ST13
Walther-plug-wiring
3 ST 2
4 ST 1
cable No.
5 ST 5
1 to 1
6 ST 3
2 to 2 …etc.
7 ST 9
PE X 2
