5.2 Selection for FX 2002 control unit (C0 = 0.10)
Note: The FX2002 control unit does not have any presettings ex works.
5.2.1 C1 Waiting time
C1 = X.XX
X.XX sec. waiting time between 2 conveying cycles.
The fan switches on after the set waiting time if the detector
(light barrier) is not active.
5.2.2 C2 Minimum operating time
C2 = X.XX
X.XX sec. minimum operating time for detectors (light barrier).
A grain flying past must not trigger a switching contact.
5.2.3 C3 Emptying suction time
C3 = X.XX
X.XX sec emptying suction time
If a timing valve is fitted, then the emptying suction time must
be set to “0“. The timing of the valve is then set via P1 and P2.
P1 active = valve open.
P2 active = valve closed.
The timing valve is connected to the terminal for the emptying
suction valve.
5.2.4 C4 Maximum fan running time
C4 = X.XX
X.XX sec. maximum fan running time.
If there is no material and the detector is not active, then the
fan switches off on reaching the set value.
5.2.5 C5 Waiting time after conveying cycle
C5 = X.XX
X.XX sec. waiting time after conveying cycle.
If there is an interruption, a new conveying cycle starts after
the set waiting time.
5.2.6 C6 – C8 Reserve
C6 –C 8 = X.XX Reserve, no function
5.2.7 C9 Programming parameters
C9 = 22.0
It is possible to select a function (C-function)
It is not possible to change the parameters (P-function)
C9 <> 22.0
It is not possible to select a function (C-function).
It is possible to change parameters (P-function).
C9 = 0.1 The works settings are loaded.
