32
IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
Typical Neutralizer Tab
Device Name - editable, 14 characters
Device/Bar Type - fixed description
Operation Mode - selectable: Fixed / Auto-Tune / CLFB / Manual
Bar HV - selectable: on / off (run / standby) neutralizers power-up in the on
/run mode
Ion Output - relative output in percentage and ionizer output current,
positive and negative, in microamps
Balance - Fixed = 50/50, Auto-Tune / CLFB system adjusts value, Manual
user adjusts value
Mounting Distance - selectable, bar type dependent
Device Address - editable, address / device number
Device Version - firmware version
Device Locator Utility - utility to briefly flash device LEDs
Alarm Test Utility - utility to briefly set device alarms for testing
The Device Page for a stand-alone (not paired) sensor bar or sensor interface is
typically a sensor tab. The tab offers detailed information and the ability to edit or
make adjustments to settings. A sensor tab typically contains more than one page,
the pages being accessed by tapping the arrow head of “Page x/x”in the upper right
of the display.
Typical Sensor Tab
• Device Name - editable, 14 characters
• Device Address - editable, address / device number
• Overall Average - averaged voltage from all sensor modules
• Feedback Average - averaged voltage from sensor modules selected for
feedback (if paired)
• Sensors for Feedback - selectable, sensor modules selected for feedback (if
paired)
• Sensor Quantity - 1 to 8 depending on quantity of sensors on bar
• Mounting Distance - selectable, controls voltage range
• Warning Setpoint - adjustable, activates bar yellow LED, set warning output
• Alarm Setpoint - adjustable, activates bar red LED, sets alarm output
• Web Voltage Sensor 1,2,3… - voltage reported by given sensor module
• Calibration Date / Firmware 1,2,3… - calibration and firmware for a given
sensor module
G. The Device Pages all contain a Home icon in the upper right corner.
Tapping this icon takes the user to the system Home Page.
H. If a yellow warning or red alarm icon appears on any page, the
icon may be tapped for a descriptive pop-up of the warning or
alarm.
