Sime Format.zip Installation Instruction And Care Guide

12
ENG
FR
max 0,5 m
max 0,5 m
C12
B52
1
4
9
C52
B52
C32
C42
3
2
11
10
C82
B22
6
5
6
12
3
11
10
3
7
1
8
3
1
3
2
3
3 2
1
3
2
3
6
3
1
8 3
Figure 9/a
IMPORTANT: In type C52 the outlet and inlet flues must not come out on opposite walls.
0,3 mt
(12 inches)
KEY
1 Separate flue kit code 8089909
2a 90° elbow MF
2b Isolated 90° elbows MF
3a Extension L. 1000 mm (39.4 inch)
3b Insulated e xtension L. 1000 mm (39.4 inch)
3c Extension L. 500 mm (19.7 inch)
4 Outlet terminal
5 Int.-est. ring kit
6 Intake terminal
7 45° elbow MF
8 Condensation outlet L. 135 mm (5.31 inch)
9 Doubler fitting
10 Tile with articulated joint
11 Roof outlet terminal L. 1390 mm (54.7 inch)
12 Tee condensation outlet
0,3 mt
(12 inches)
