7
www.SimmonsDrums.net
Assembly instructions
Step 1:
Remove the pad/module from the packing. Attach the front steel
tube unit to the pad/module with 2 provided screws and tighten.
(For better leverage and visibility, you may want to compete this
step with module/pad turned upside down).
Step 2:
Insert the back steel drum legs into the pad/module securely as
shown, and tighten each with the provided screws.
Step 4:
Insert the cymbal L-arm mounts into their respective holes as shown
and tighten each of the hex wingnuts. Use large knob on the left to
tighten the arm mount.
Step 3:
Insert the snare pad onto the snare rod mount as shown, and tighten
the wingnut.
