6
OWNER’S MANUAL
ASSEMBLING YOUR KIT
STEP 1 - DRUM RACK
The Drum rack will be fully assembled in the box.
Remove the drum rack from the box and tighten
the connecting clamps until the kit is stable.
STEP 2 - ATTACH CYMBAL ARMS
Insert each cymbal arm into the rack clamp.
arm’s cymbal clamp. Slide the hi-hat arm
through the plastic sleeve to adjust the height.
STEP 3 - ATTACH CYMBAL PADS
Place the cymbal pads on the tilter assemblies
and felt to the hi-hat arm.
STEP 4 - ATTACH DRUM MODULE
Loosen the wing screw on the module mount
located on the crossbar. Place the drum
module into the drum clamp. Tighten the
wing screw to secure the module.
