06 07
Note:
• The transmitter will automatically enter standby mode within 5 minutes of no
signal input, and it will automatically restart when there is an audio signal
input.
• The headphone will power off automatically after 10 minutes of no audio signal
in. Using it again, you need to slide ON/OFF switch to “OFF” position, then
slide to “ON”. Be aware, the headphone will not automatically power off in the
ambient sound mode unless the battery is dead.
HOW TO USE
SM-829D2 is compatible with OPTICAL output, RCA (labeled “AUDIO OUT”)
and AUX 3.5mm output (Ref. Fig 1-1).
2.1 Power the Transmitter (Ref. Fig 2-1)
Plug the supplied AC adapter into a standard electrical outlet, plug the other end
of the AC adapter into the port labeled “DC 5V” on the back of the transmitter.
2. Turn on the Transmitter and Headphone
1. Check Your TV/Audio Source Output Options before the Set up
Note:
• Three different audio cables included: digital optical cable, RCA cable and
3.5mm cable. In the end, only one of these cables is needed to complete the
installation.
• If your audio source device has an optical audio out port, please connect
SIMOLIO to this port preferentially. If not, you can also connect SIMOLIO to
the RCA or AUX/3.5mm or other audio out port of the audio source device.
Other RCA
jacks(usually
audio in)
AUDIO IN
Digital Optical
AUDIO OUT
OPTICAL
AUDIO OUT
(need extra 6.35mm
to 3.5mm adapter,
purchase separately)
(need extra digital to
analog converter,
purchase separately)
Digital
AUDIO OUT
Coaxial
COAXIAL
Jack
Options
Natively
supported?
Please refer
to Point
6.35mm
Phone jack
PHONE
3.1
AUX/3.5mm
3.3
RCA jacks
labled
AUDIO OUT
R
L
AUDIO OUT
3.2
N/A
3.4 3.4
Fig 1-1
R
L
3.1 Digital Optical Connection
This part will instruct you on how to connect the SIMOLIO transmitter
to your television, satellite, or cable box using an optical digital audio cable.
SM-829D2
3. Connect the Transmitter to Your TV/Audio Source
Set the volume of the audio source to a level sufficient for people with normal
hearing to clearly listen to the TV to ensure stable audio output.
i.e. set the TV box VOL ≥ 30 % & TV VOL≥ 40% (Ref. Fig 3-1) (Ref. Fig 3-2)
For watching TV quietly without disturbing others, the right way is: Mute your TV
by pressing the MUTE button on the remote control or choose any speaker option
other than TV Speaker in the TV Sound Output settings (Ref. Fig 3-3).
• The above settings may differ from various TVs.
TV box VOL ≥ 30 %
Fig 3-1
Mute
Fig 3-3
TV VOL ≥ 40 %
Fig 3-2
Fig 2-2
Power in
Power adapter
Transmitter
Fig 2-1
S
T
E
R
E
O
O
FF
M
O
N
O
D
C 5V
P
OWER IN
DC 5V
S
TE
RE
O
M
ONO
OFF
O
N / OFF
O
N/
OF
F
2.2 Turn on the Transmitter (Ref. Fig 2-2)
Slide MONO/STEREO/OFF switch to“MONO” or “STEREO” position.
2.3 Turn on the H
Slide ON/OFF switch to “ON” position .
eadphone (Ref. Fig 2-3).
Note:
Please charge the headphone for 3 hours
before using it for the first time.
Fig 2-3
R
SM-829D2 SM-829D2
POW
E
R IN
DC 5
V
AU
X
STER
EO / M
O
NO / OFF
OPT
IC
A
L
OPT
IC
A
L
A
UX
IN
PUT FR
O
M T
V
O
N / OFF
OUTP UT TO SPEA KER
