4. A SSEMBLY I NSTRUCTIONS
Assembly Instruction
14
Attach one end of the pressure hose (18) to the spray gun (3) .Take down the air shield on pump
water outlet (13), then attach to the other end of the pressure hose and fasten.
Note: please make sure all the quick connectors are connected in the right direction.
８
Now your pressure washer is fully assem-
bled.
CAUTION
Do not operate the product before you read and
fully understand next chapter → Engine opera-
tion.
