8
5. assembly InstructIons (cont.)
5.4 Assembly Steps (cont.)
F
Attach the high-pressure hose to the gun and pump outlet
(hand tighten only).
G
Rotate the nozzle to the predened spray pattern. Each spray
pattern has the following purpose:
• 0º: For tough spots and grimes
(e.g., concrete surfaces).
• 15º: For medium cleaning tasks
(e.g., driveway).
• 40º: For light-duty jobs and rinsing
(e.g., stucco walls, glossy surfaces).
H
Connect garden hose to the inlet adaptor (hand tighten only).
Assembly Instructions
0°
15°
40°
