Simplex 4005 User Manual

1-5
110 VAC: 3A @ 120 VAC, 60 Hz
240 VAC: 1.5A @ 220/240 VAC, 50/60 Hz
24 VDC, 6.2Ah to 33Ah
CAUTION: The 4005 must be grounded properly. Readings of less than
0.70 VAC must be measured between ground and neutral. A
system ground must be provided for Earth Detection and
transient protection devices. This connection shall be made
to an approved, dedicated Earth connection per NFPA 70,
article 250, and NFPA 78. Connect a 12 AWG copper
ground wire from safety ground (electrical distribution panel)
to the 4005 grounding terminal on the AC terminal block.
Specifications
Input Power
Battery Backup
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
