Simplex 4005 User Manual

1-2
Tables 1-1 and 1-2 describe Base Panel and Optional components of the 4005
with their associated Product (PID) numbers and Part numbers.
Table 1-1. 4005 Base Panel Product and Part Numbers
Description Product No. Part No.
4005 Base Panel (beige) 4005-9101
566-151 (CPU)
4005 Base Panel (red) 4005-9102
566-252 (Pwr Supply)
4-Circuit IDC Card (low-current) 4005-9804 565-473
4-Point NAC/Relay Card 4005-9805 565-477
Five Slot Power Distribution Module 4005-9807 565-471
Table 1-2. 4005 Optional Module Product and Part Numbers
Description Product No. Part No.
2-IDC/2-NAC/Relay Card 4005-9803 565-552
Class A Adapter Card 4005-9806 565-556
8-Point I/O Card 4005-9808 565-554
City Circuit Card 4005-9809 565-550
DACT Card 4005-9810 565-626
Expansion Power Supply 4005-9813 565-481
4-Circuit IDC Card (high-current, Class B) 4005-9824 565-610
The 4005 is a microprocessor-based, battery-backed, electrically-supervised fire
alarm system capable of supporting from 8 to 40 circuits. These circuits, either
initiating device circuits (IDC) or notification appliance circuits (NAC), are
added to the system in blocks of four. In addition, the 4005 can automatically
control supplementary equipment such as fire doors and fans during a fire
condition using NACs converted to auxiliary relay outputs.
The 4005 provides audible and visible indications during trouble, supervisory, or
alarm (fire) conditions. Should any of these conditions occur, the system
activates the applicable notification appliance(s), LEDs, and the panel tone-alert.
The indications continue until someone appropriately acknowledges the
condition.
Figure 1-1 illustrates the physical layout of the cards and wiring areas within the
base 4005 panel. The I/O cards plug into slots of the Power Distribution Card(s)
along either side of the CPU. A maximum of 10 slots are available. The non-
power-limited wiring area is shaded.
Continued on next page
Description and Features
Product and Part Numbers
Description
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
