4 S4006-0001-8 8/2012
Power Ratings
AC Input Ratings
Input Voltage 120 VAC, 60 Hz; 220/230/240 VAC, 50/60 Hz, auto-select
Input Current, Standard 2 A maximum @ 120 VAC input; 1.5 A maximum @ 240 VAC input
Input Current with
Expansion Power Supply
4 A maximum @ 120 VAC input; 3 A maximum @ 240 VAC input
Power Supply Output Rating 3 A maximum @ 24 VDC in alarm (see NAC details on page 6)
Battery Charger
Temperature compensated charger is rated for up to 25 Ah per UL 864; up to
12.7 Ah per ULC-S527
Standby Current 130 mA; with 5 IDCs fully loaded, tone-alert silenced, trouble LED on
Standard Circuit Ratings (NOTE: Total DC current = 3 A maximum)
Notification Appliance Circuits (NACs)
NOTE: See details on page 6
2 A maximum @ 24 VDC, per circuit; available as Class A or Class B;
Class B end-of-line resistor = 10 k, 1/2 W; Model 4081-9008 (P/N 733-894)
Initiating Device
Circuits (IDCs)
Supervisory Current 3 mA maximum
Alarm Current 60 mA maximum
Capacity
Each IDC supports up to 30 detectors (smoke or electronic heat) and manual
stations as required; wiring distance is limited to 50 Ω maximum
End-of-Line Resistor 3.3 k, 1/2 W; Model 4081-9002 (P/N 733-893) for Class B IDCs
Annunciator
Communications
Quantity Supported Up to four annunciator modules per panel (see page 5 for details)
Wiring Type Twisted pair, or twisted, shielded pair; 18 AWG (0.82 mm
2
)
Bus-Style Wiring Up to 4000 ft (1219 m); 0.58 µF (580 nF) maximum capacitance; 35 max.
“T-Tap” Wiring Up to 10,000 ft (3048 m) total wiring; up to 2500 ft (762 m) to farthest device
Line Matching Resistor
Bus-style, connect one at panel and one at end of line
100 , 1/2 W; 4081-9011;
(part number 733-974)
T-Tap, connect one at panel and one at farthest device
Suppression
Use 2081-9044 Overvoltage Protectors where wiring leaves and enters a building
(refer to data sheet S2081-0016)
Auxiliary Power Output 500 mA maximum @ 24 VDC
Standard Auxiliary Relay Outputs
Relay 1 Programmable operation
Contacts rated 2 A @ 30 VDC, 0.35 power factor;
jumper selectable as N.O. or N.C.
Relay 2 Trouble operation
Wiring Connections for Above Circuits and
AC Input
Terminals rated for 18 AWG to 12 AWG (0.82 mm
2
to 3.31 mm
2
)
Option Module Ratings
Class A IDC Adapter Module Five circuits per module, rated same as circuits
Ten Relay Auxiliary
Module 4006-9803
Contact Ratings 2 A @ 30 VDC, 0.35 power factor; jumper selectable as N.O. or N.C.
Wiring Terminals rated for 18 AWG to 12 AWG (0.82 mm
2
to 3.31 mm
2
)
Environmental Ratings
Operating Temperature Range 32° to 120°F (0° to 49° C)
Operating Humidity Range Up to 93% RH, non-condensing @ 100.4° F (38° C) maximum
Compatible Simplex Detectors
Model Type Description Data Sheet
4098-9601
Photoelectric smoke detectors
for 2-wire and 4-wire bases
Standard detector (2.8% nominal)
S4098-0015
4098-9605 Reduced sensitivity detector (3.5% nominal)
4098-9602 Combination smoke and heat detector S4098-0017
4098 Series Duct detector housings 2-wire and 4-wire models S4098-0029
4098 Series Ionization Smoke Detectors 2-wire and 4-wire models S4098-0018
4098-9612
Electronic heat detectors for
2-wire and 4-wire bases
135° F (57°C)
Fixed temperature heat detector
S4098-0014
4098-9614 200° F (93°C)
4098-9613 135° F (57°C)
Fixed temperature heat detector with
rate-of-rise detection
4098-9615 200° F (93°C)
Compatible System Expansion Panels
Model Type Description Data Sheet
4003 Series Voice Control Panel
Provides a remote voice control panel with on-board NACs, internal
microphone, and remote microphone input
S4003-0002
4009 Series Remote NAC Extender
Provides remote NACs; includes power supply and battery charger;
4 extenders max/NAC; 4006 uses NAC output to provide control
S4009-0002
Note: Contact your local Simplex Product Supplier for additional compatible peripherals.
Specifications (Refer to Installation Instructions 579-704 for additional information)
Reference Information, Compatible Simplex Peripherals
