Simplex 4006 Series User Manual

The following IDC operation modes are selectable from either the front panel or the PC programmer
6 S4006-0001-8 8/2012
Function Type Description Device State IDC Status
FIRE Fire monitor zone
Normal =
Current Limited =
Short =
Open =
NORMAL
FIRE
FIRE
TROUBLE
WATER Waterflow monitor zone
Normal =
Current Limited =
Short =
Open =
NORMAL
FIRE
FIRE
TROUBLE
HEAT Heat detector zone
DUCT Duct detector zone
PULL Manual (pull) station zone
SMOKE Smoke detector zone
SO Sprinkler Supervisory
Normal =
Current Limited =
Short =
Open =
NORMAL
SUPERVISORY
SUPERVISORY
TROUBLE
WSO
Combination waterflow and water supervisory
zone
Normal =
Current Limited =
Short =
Open =
NORMAL
SUPERVISORY
ALARM
TROUBLE
SUPV Supervisory monitor
Normal =
Current Limited =
Short =
Open =
NORMAL
SUPERVISORY
SUPERVISORY
TROUBLE
UTIL Supervised utility monitor
Normal =
Current Limited =
Short =
Open =
OFF
ON
ON
TROUBLE
TROUBLE Trouble monitor
Normal =
Current Limited =
Short =
Open =
NORMAL
TROUBLE
TROUBLE
TROUBLE
VSMOKE
Verified fire alarm; the abnormal (current limited)
state causes the alarm verification cycle to start;
a short is an immediate alarm
Normal =
Current Limited =
Short =
Open =
NORMAL
VERIFY
FIRE
TROUBLE
STYLEC Style C fire monitor
Normal =
Current Limited =
Short =
Open =
NORMAL
FIRE
TROUBLE
TROUBLE
LATSUPV
Latching supervisory monitor (supervisory
latches until system is reset)
Normal =
Current Limited =
Short =
Open =
NORMAL
SUPERVISORY
SUPERVISORY
TROUBLE
NAC Ratings, Maximum per NAC Appliances
Special Application: 2 A;
strobe synchronization is UL listed across all 4
system NACs for these 4906 Series appliances
Simplex 4901 Series (horns) and 4906 Series Multi-Candela non-addressable
strobes, horn/strobes, and speaker/strobes (contact your Simplex product
representative for compatible appliances)
Regulated 24 VDC: 1.5 A
NOTE: Maximum strobe
load on main power
supply or expansion power supply is 1.35
A per
power supply (2.7 A total); remainder of power
supply rating is available for other loading
Power for other UL listed appliances; use associated external synchronization
modules where required
IDC Operation Modes
Detailed NAC Ratings
