6
• Local mode operation is limited to general alarm. Any point type listed in Table 4 is valid for
local mode alarm operation. Note that the point must be an alarm-type point. On any alarm
input, all circuits listed in Table 5 will activate.
• Input Operation:
During local mode operation, TrueAlarm initiating devices connected to the transponder will
cause an alarm at their least sensitive alarm threshold.
- Photoelectric sensors will alarm at 3.7%/ft smoke obscuration
- Ionization sensors will alarm at 1.3%/ft obscuration
- Heat sensors will alarm at a fixed temperature of 135° F (57° C).
• Notification Operation:
Notification appliance circuits operate per the point type selected in the programmer, with the
exception of 20 BPM march time, which operates at 60 BPM.
If a NAC is programmed for SQALERT point type, the audible appliances will sound as
programmed and the strobes will flash synchronized at 1 Hz.
Voice NACs play the horn tone at temporal-coded cadence.
• TrueAlarm sounder bases are limited to “on steady” operation. A coded NAC must be used to
drive the 24V power to the sounder base if coding is necessary. TrueAlarm device LEDs
operate as usual.
Continued on next page
TICs and Audio Riser Modules,
Continued
Local Mode
