Table 4. Alarm Input Devices
Point Type Description Curr. Lim. Short
FIRE Fire alarm (generic) Alarm Alarm
WATER Waterflow switch Alarm Alarm
HEAT* Heat detector Alarm Alarm
DUCT* Duct detector Alarm Alarm
FLAME Flame detector Alarm Alarm
PULL Pull station Alarm Alarm
SMOKE* Smoke detector Alarm Alarm
VSMOKE* Verified smoke detector Alarm Alarm
EMERG Combination fire/emergency Supv Alarm
SFIRE Combination smoke/fire Alarm Alarm
VSFIRE Verified combination smoke/fire Alarm Alarm
SPULL Combination smoke/pull Alarm Alarm
VSPULL Combination verified smoke/pull Alarm Alarm
S2STAGE 2-stage monitor Alarm Alarm
WSO Combination waterflow/tamper Supv Alarm
WSC Combination waterflow/tamper Normal Alarm
GVMON* Generic verified monitor Alarm Alarm
STYLEC Style-C monitor Alarm Trouble
GENFS Generic fire/supervisory (normally open) Supv Alarm
SUPDET Suppression agent monitor zone Alarm Alarm
SUPDUMP Suppression agent manual dump Alarm -
SUPPRES Suppression pressure switch monitor Alarm Trouble
Table 5. Notification Appliance Circuit Types
Point Type Description
SSIGNAL Alarm signal (will activate to Programmer specified default coding)
RSIGNAL Alarm signal (will activate to Programmer specified default coding)
SVISUAL Visual signal (will activate on steady)
RVISUAL Visual signal (will activate on steady)
SPEAKER Speaker circuit (will turn on steady – temporal horn tone from local tone
generator)
SQALERT Signal/Visual on until silence (horn will activate on steady)
SSYNVIS Strobes on until silence
RSYNVIS Strobes on until reset
All TrueAlert visual devices will code according to their configuration before local mode activated
(no virtual NAC support)
