1.1.3 Addressable Device Faults
To confirm a Loop card is in NORMAL status:
 Press the MENU button.
 Scroll through the options until CARD STATUS is reached.
 Press the ENTER button
 Scroll through the cards in the panel. Confirm that each loop card is NORMAL.
 If CARD MISSING FAILED ABNORMAL then press ENTER and Scroll through card faults.
 Refer to the relevant section for fault descriptions.

1.1.3.1.1 No Answer
Description:
The panel has a device programmed at the address displayed that is not responding.
Possible causes:
1. Device is not fitted or wiring not correctly terminated.
2. Addressable loop is not working correctly (loop is broken)
3. Faulty base or device
Suggested solutions:
NO
YES
Check
device
Address
Check Loop is
powered at device
(30V)
Is device LED
flashing?
NOTE - It is vital that the Loop card is in
NORMAL status before addressable
device fault finding is started.
!
