Page #8 background imageLoading...
Page #8 background image
TYCO, SIMPLEX, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited.
Tyco Fire Protection Products • Westminster, MA • 01441-0001 • USA S4100-0034-12 3/2012
www.simplexgrinnell.com
© 2012 Tyco Fire Protection Products. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Input Powe
r
Power Supplies; SPS,
XPS, and RPS
120 VAC Models; 4 A maximum @ 102 to 132 VAC, 60 Hz
220-240 VAC Models; 2 A maximum @ 204 to 264 VAC, 50/60 Hz; with taps for 220/230/240 VAC
100 W Amplifier Power
Supplies
120 VAC Models; 4 A maximum @ 102 to 132 VAC, 60 Hz
220-240 VAC Models; 2 A maximum @ 204 to 264 VAC, 50/60 Hz; with taps for 220/230/240 VAC
Amplifier Ratings
Built-in Tones
500 Hz horn tone operated at temporal pattern, provided when amplifiers are separated from
audio controller
Flex-35 Amplifiers:
4100-1361
4100-1362
4100-1363
4100-1364
Input Voltage 19 to 35 VDC from adjacent power supply
Supervisory Current
425 mA with power stage supervised
85 mA in low power mode
Alarm Current
@ full output power
5.5 A with continuous horn tone
Use this value for power
supply loading
1.64 A average, with temporal pattern horn
Use this value for battery
backup reference
Flex-50 Amplifiers:
4100-1312
4100-1313
4100-1326
4100-1327
Input Voltage 19 to 35 VDC from adjacent power supply
Supervisory Current
425 mA with power stage supervised
85 mA in low power mode
Alarm Current
@ full output power
5.55 A with continuous horn tone
Use this value for power
supply loading
2.27 A average, with temporal pattern horn
Use this value for battery
backup reference
100 W Amplifiers and Backup Amplifiers:
4100-1314, 4100-1316, 4100-1318,
4100-1320, 4100-1322, 4100-1324;
4100-1328, 4100-1330, 4100-1332,
4100-1334, 4100-1336, 4100-1338
Supervisory Current
400 mA (analog); 220 mA (digital) with power stage supervised
85 mA in low power mode
Alarm Current
@ full output power
9.6 A with continuous horn tone
3.8 A average, with temporal pattern horn
Use this value for battery
backup reference
Total Amplifier Power per Cabinet 300 W maximum
Audio Controller Ratings
Current
Requirements
4100-9620, 4100-1210 Analog = 225 mA supervisory
Add for local speaker in alarm: 75 mA min. volume;
190 mA half volume; 333 mA full volume;
Add microphone current separately; Supv.= 2.4 mA;
Active = 30 mA
4100-9621, 4100-1311 Digital = 85 mA supervisory
Analog Riser Distance Up to 10,000 ft (3048m) total with 18 AWG (0.82 mm
2
) shielded twisted pair (STP)
Digital Riser Distance; 18 AWG
unshielded, twisted pair (UTP) required,
except as noted (refer to Installation
Instructions 574-844)*
Up to 2500 ft (762 m) from 4100-1311 Digital Controller to 4100-0622 Digital Audio Riser or
4100-1341 MCC Digital Riser Interface; up to 2500 ft (762 m) between 4100-0622 Digital
Audio Riser Modules or 4100-1341 MCC Digital Riser Interfaces (signal is reformatted and
repeated); wire runs over 100 ft (30 m) require UTP wire
* NOTE: Wire runs of 100 ft (30 m) or less require shielded twisted pair wire (STP)
Firefighter Telephone Distance Ratings
Distance 7500 ft (2286 m) distance to farthest phone, 18 AWG shielded twisted pair (STP)
Battery Charger, System and Remote Power Supply (sealed lead-acid batteries)
Battery capacity range
UL listed for battery charging of 6.2 Ah up to 110 Ah (110 Ah batteries require a remote battery
cabinet); ULC listed for charging up to 50 Ah batteries
Charger characteristics and performance
Temperature compensated, dual rate, recharges depleted batteries within 48 hours per UL
Standard 864, to 70% capacity in 12 hours per ULC Standard S527
Environmental
Operating Temperature Range 32° to 120°F (0° to 49° C)
Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Subject Data Sheet Subject Data Sheet Subject Data Sheet
Basic Panel Modules S4100-0031 Network Display Unit (NDU) S4100-0036 InfoAlarm Comm. Center S4100-0045
LED/Switch Modules S4100-0032 Enclosures S4100-0037 Remote Battery Charger S4081-0002
MINIPLEX Transponders S4100-0035 Remote Annunciators S4100-0038 Remote Firefighter Phones S2084-0001
Additional 4100ES Data Sheet Reference
General Specifications
