ENGINE:
24 HP* Briggs & Stratton
Make Briggs & Stratton
Model Extended Life Series with EFM
Horsepower 24 @ 3600 rpm
Displacement 49.4 cu in. (810 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 340 CCA
Oil Capacity 64-68 oz (1,9-2,0 L)
Spark Plug Gap 0.030 in. (0.76 mm)
The spark ignition system complies with Canadian standard
ICES-002.
CHASSIS:
Fuel Tank Capacity 4.0 Gallons (15 L)
Rear Wheels Tire Size: 23 x 10.5 -12
Inflation Pressure: 6-8 psi (,41-,55 bar)
Front Wheels Tire Size: 16 x 6.5-8
Inflation Pressure: 12-15 psi (,8-1 bar)
TRANSMISSION:
K66
Type Hydrostatic Tuff Torq K66
Hydraulic Fluid 10w 30 Premium Engine Oil
Capacity 2.6 qt (2,5 L)
Speeds Forward: 5.8 MPH (9,3 km/h)
@ 3400 rpm Reverse: 3.5 MPH (5,6 km/h)
Continuous Torque 310 ft-lbs (419 Nm)
Output
Drawbar Rating 440 lbs (200 Kg)
Maximum Weight 674 lbs (306 Kg)
on Axle
DIMENSIONS:
Overall Length 75” (190,5 cm)
Overall Width 62” (157,5 cm)
Height At Top of Seat: 47” (119,4 cm)
Engine Power Rating Information
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engineers)
code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and corrected in
accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are derived at 3600
RPM. Actual gross engine power will be lower and is affected by, among other things, ambient operating conditions and engine-to-
engine variability. Given both the wide array of products on which engines are placed and the variety of environmental issues
applicable to operating the equipment, the gas engine will not develop the rated gross power when used in a given piece of power
equipment (actual "on-site" or net power). This difference is due to a variety of factors including, but not limited to, accessories (air
cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature,
humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may
substitute an engine of higher rated power for this Series engine.
Replacement Parts
Replacement parts are available from your authorized
dealer. Always use genuine Simplicity Service Parts.
Technical Manuals
Additional copies of this manual are available, as well as
fully illustrated parts lists. Technical manuals can be
downloaded from www.simplicitymfg.com.
Dozer Blade 42”
Dump Cart
Catcher Triple Bag Collector
Wheel/Tire Chains
Dethatcher (requires adapter)
Dethatcher Adapter
Mulching Kit
Rear Attachment Kit
Snow Thrower Cab
Snow Thrower Attachments
Dozer Sub Frame
Tiller
Turbo Collector
Front Weight Carrier
Rear Weight Carrier
Wide Body Cart Collector
Utility Bucket
Engine Oil
Touch-Up Paint
Grease Gun Kit
8 oz Grease Tube
Tire Sealant
Degrimer/Degreaser
Gas Stabilizer
Optional Accessories
Maintenance Items
Many convenient and helpful service and maintenance
items are available from you authorized dealer. Some of
these items include:
35
SPECIFICATIONS / PARTS AND ACCESSORIES
