Simplicity Regent Hydro-Gear 0650 Series

16 - 1
16 Mower Deck Service
Table of Contents
SECTION CONTENTS
Exploded View Diagrams
38” Mower Deck - Housing, Arbors, & Blades............................ 16-2
38” Mower Deck - Belt, Idler Arm, & Hitch - Early Models.......... 16-4
38” Mower Deck - Belt, Idler Arm, & Hitch - Later Models ......... 16-6
38” Mower Deck - Height Adjustment & Gauge Wheels ............ 16-8
44” Mower Deck - Housing, Arbors, & Blades.......................... 16-10
44” Mower Deck - Belt, Idler Arm, & Hitch ............................... 16-12
44” Mower Deck - Height Adjustment & Gauge Wheels .......... 16-14
Idler Pulley Replacement
Idler Pulley Replacement ......................................................... 16-16
Arbor Service
Arbor Removal & Installation.................................................... 16-16
Arbor Disassembly................................................................... 16-17
Arbor Assembly........................................................................ 16-18
SECTION 16. MOWER DECK SERVICE
