9 Drive Controls Service
Hydro-Gear 0500 / 0650 Models
Transmission Control Linkage
Removal & Installation
Refer to Figure 10.
TRANSMISSION CONTROL ROD
1. Remove the nut (G), lockwasher (F), washer (E),
spacer (D) and carriage bolt (A) connecting the trans-
mission control rod (B) to the foot pedal arm.
2. Remove the cotter pin and washer (C) connecting the
rear of the transmission control rod (B) to the pivot
lever (Q). Remove the rod.
Install in reverse order of removal. After installation, per-
form GROUND SPEED CONTROL FOOT PEDAL
ADJUSTMENT procedure in Section 4.
NEUTRAL ADJUSTMENT LINKAGE
1. Disconnect the transmission control rod (B) from the
pivot lever (Q).
2. Remove the capscrew (H) securing the spring (J).
3. Remove the nut (X), lockwasher (W), and carriage
bolt (U). Remove the neutral adjustment rod (V).
Install in reverse order of removal. After installation, per-
form NEUTRAL ADJUSTMENT, and GROUND SPEED
CONTROL FOOT PEDAL ADJUSTMENT procedures in
Section 4.
