Simplicity Regent Hydro-Gear 0650 Series

16 - 11
16 Mower Deck Service
44” Mower Deck - Housing, Arbors, & Blades
Ref. Qty. Description
1 3 NUT, Hex, Flange, 9/16-8
2 6 WASHER, Belleville
3 2 PULLEY, RH Arbor & LH Arbor
4 1 HUB, Adapter (LH)
5 3 COVER, Arbor Housing
6 3 BEARING, Upper
7 3 SPACER, Sleeve, Upper Bearing
8 3 SPACER, Arbor, Internal
9 3 BEARING, Lower
10 3 GASKET, Foam
11 3 ARBOR HOUSING ASSY. (Incl. Fitting Ref. 12)
12 3 FITTING, Grease
13 1 COVER, Arbor (LH)
14 27 SCREW, Hex, Taptite, 5/16-18 x 3/4
15 3 WASHER
16 1 SHAFT, Arbor (LH)
17 3 SHIELD, Grass, Lower
18 3 BLADE, Mower, 16-1/8”
19 3 WASHER, Hex
20 3 WASHER, Spring
21 3 CAPSCREW, Hex, Hd., 7/16-14 x 1
22 1 SHAFT, Arbor (RH)
23 1 HOUSING ASSY, Orange
23 1 HOUSING ASSY, Black
24 1 COVER, Arbor (RH)
25 2 CARRIAGE BOLT, 1/4-20 x 7/8
26 2 NUT, Push On
27 2 WASHER, Plain
28 1 CLAMP
29 1 WASHER, Plain, 5/16
30 1 SPRING, Deflector Retaining
31 2 LOCKWASHER, 1/4
32 2 NUT, Hex, 1/4-20
33 1 ROD, Deflector, Front
34 1 PLUG, Hole
35 1 DEFLECTOR, Plastic
36 1 HUB, Pulley (RH)
37 1 PULLEY, Arbor (Center)
38 1 HUB, Pulley (Center)
39 1 SHAFT, Arbor (Center)
44” Mower Deck - Housing, Arbors, & Blades
