Introduction
+(1.0% of reading +2 digits), 10 kHz to
20 kHz, except 600V range, which is 400
Hz to 20 kHz
Sensitivity: 1004V on 200 mV range
Full Range Step Response
(to rated accuracy): 5 seconds
Overrange Capability: Linear to 500 counts beyond maximum
indication (except on 600V range, where
any indication greater than 600 is an
overload).
Temperature Coefficient
(from 0°C to +55°C): +(0.05% of reading +0.1 digit)/°C
3. Resistance:
A. LO OHMS (Maximum Open-Circuit Voltage = 1V)
Maximum Full Scale Test Overload
Range Indication Voltage Current Protected To
2002 199.9 2 200mV 1тА 135V rms
2k? 1.999 ко 200mV 1004A 135V rms
20k? 19.99kQ 200mV 104A 250V rms
200kQ 199.9kQ 200mV ТА 250V rms
2000к9 1999к0 200mV 100nA 250V rms
B. HI OHMS
Maximum Full Scale Test Overload
Range
Indication
Voltage
Current
Protected
To
2к9
1.999kQ
2V
1mA
135V
rms
20kQ 19.99kQ 2V 1004A 250V rms
200k?
199.9k2
2V
104A
250V
rms
20009
1999kQ
2V
lunA
250V
rms
20M2
19.99M9
2V
100nA
250V
rms
Accuracy (from +15°C
to +35°C): +(0.25% of reading +1 digit) except on
the 2000 КО and 20 М? ranges, which
are +(0.5% of reading +2 digits)
Sensitivity: 0.12 on 2002 range
Full Range Step Response
(to rated accuracy): 1 second, except on 20 M9 range, which
is 10 seconds
Temperature Coefficient у
(from 0°C to +55°C): +(0.02% of reading +0.1 digit)/?C
