Page 7
COMPONENT LOCATION
5
4
2
3
1
1 - Handle
2 - Accessory Storage - Provides convenient storage for the included
nozzles and strap to hold the high-pressure
hose and electrical cord.
3 - Master ON/OFF
Switch
- Push the switch in to turn the pressure washer
ON. Push the switch again to turn the pressure
washer OFF.
4 - Thermal Relief
Valve
- This protective device will release hot water
from the pump when you are not spraying
water. If you will not spray for more than one
minute, turn the pressure washer OFF.
5 - Electric cord with
GFCI
- The pressure washer and operator are
protected by a ground fault circuit interrupter
(GFCI). See page 15 for more information.
