Simrad AP48 Quick Guide

AP48 | Quick Guide - EN
Autopilot modes
Mode Activate Rotary knob Port and
starboard
keys
Standby
STBY
Press to
activate FU
mode.
Press to
activate NFU
mode.
Follow-up From any mode: select the Follow-up
option in the Mode list.
From Standby mode: press the rotary
knob.
Rotate to
adjust the
rudder angle.
Press to
activate NFU
mode.
Non Follow-
up
Switch to NFU mode by pressing one
of the port or starboard keys when the
autopilot is in Standby mode or FU mode.
Press to
activate FU
mode.
Press to adjust
the rudder
angle.
AUTO
AUTO
Rotate to
adjust the set
heading.
Press to
adjust the set
heading.
Wind From any mode: select the Wind option in
the Mode list.
¼ Note: Only available when boat type
is set to SAIL.
Rotate to
adjust the set
wind angle.
Press to adjust
the set wind
angle.
Wind NAV From any mode: select the Wind NAV
option in the Mode list.
¼ Note: Only available with AC12/42
autopilot computers when the boat
type is set to SAIL. Not available with
NAC-2 or NAC-3 autopilot computers.
Rotate to
adjust the set
wind angle.
Press to adjust
the set wind
angle.
NAV From any mode: select the NAV option in
the Mode list.
¼ Note: NAV mode requires a
compatible chartplotter connected to
the network.
No action. No action.
NoDrift From any mode: select the NoDrift option
in the Mode list.
Rotate to
adjust the set
heading.
Press to
adjust the set
heading.
|
3
