Simrad BSM-2 - Technical Specification

BSM-2 Installation manual | 17
ENGLISH
Compliance and Environmental
Compliance CE, C-TICK
Technical
Standards
IEC 60945,
IEC 60529
Waterproof IPX5
Humidity Up to 95% at 35°C non-
condensing
Storage
Temperature
–30°C to +70°C
Operating
Temperature
–15°C to +55°C
General
Connectors 6 Glands and 1 Ethernet Glands: Depth transducer
(x2), Temperature (x2), Speed
transducer, Power Connector: 5
pin Yellow RJ45
Weight 4.8 kg (10.6 lbs) Die Cast Aluminum
Dimensions
(WxHxD) mm/
in
340x100x289 mm
(13.38x3.94x11.37 inches)
With watertight glands and
connector outside dimensions
included
Mounting 4 keyholed mounting tabs Mount below deck but NOT in
engine compartment
Sonar Specications
Power Output 250 Watts RMS
2,000 Watts (peak to
peak)
With CHIRP; Transducer
dependent with 3 impedance taps
Power requirements
Power
Consumption
Range dependent –
normally less than 10W
3A internal fuse
Technical specication
